TVS LP46 Plus Thermal Transfer & Direct Label Printer | 4 inch | 203 dpi | USB+Ethernet | 2 year warranty
Review: 5 - "A masterpiece of literature" by , written on May 4, 20020
Great

TVS LP46 Plus Thermal Transfer & Direct Label Printer | 4 inch | 203 dpi | USB+Ethernet | 2 year warranty

Available:In Stock


Total Price : Rs. 16,536.00 (Rs. 19,512.48 Incl. of all taxes)

(Tax & Fright Extra)

Price Excluded GST Tax & Shipping

Click Here For Bulk Enquiry

+91 8411958300




info@srkinnovations.com

  • Brand : TVS
  • Model Name : LP46+
  • Special Feature : Desktop
  • DPI : 203 dpi
  • Interface : USB+Ethernet
  • Max Print Width : 4 inch
  • Max Print Speed : 152 mm/sec
  • Weight : 2.4 kg
  • Warranty : 2 Year Warranty in all products
  • SDK and APIs are available for support
X

TVS LP46 Plus Desktop Label Printers combine performance with reliability and offer High-Resolution labels. This Desktop Barcode Printer redefines printing by using the latest technology. Its movable Black Mark Sensor 46 has the unique capability of sensing black marks on labels and receipts, making it the ideal printer for printing cinema/theatre tickets. These are appropriate for Manufacturing and Warehousing, Healthcare, Small offices, and Logistics.


ADVANTAGES
  • High Memory capacity of 128 MB Flash and 64 MB SDRAM
  • Supports multiple interfaces
  • Supports both 0.5″ and 1″ Ribbon core

TVS LP46 Plus Desktop Label Printers combine performance with reliability and offer High-Resolution labels. This Desktop Barcode Printer redefines printing by using the latest technology. Its movable Black Mark Sensor 46 has the unique capability of sensing black marks on labels and receipts, making it the ideal printer for printing cinema/theatre tickets. These are appropriate for Manufacturing and Warehousing, Healthcare, Small offices, and Logistics.


ADVANTAGES
  • High Memory capacity of 128 MB Flash and 64 MB SDRAM
  • Supports multiple interfaces
  • Supports both 0.5″ and 1″ Ribbon core

Printing Model

TVS LP46 Plus Thermal Line Printing - Direct Thermal & Thermal Transfer

Resolution 8 dots/mm (203 DPI)
Printing Method Thermal Line Printing - Direct Thermal & Thermal Transfer

Max. print speed

152.4 mm (6")/second

Max. print width

108 mm (4.25“)

Print length

2,794 mm (110")

Enclosure

ABC plastic

Physical dimension

204 mm (W) x 164 mm (H) x 280 mm (D)
8.03" (W) x 6.46" (H) x 11.02" (D)

Weight

2.4 kg

Label roll capacity

127 mm (5") OD

Ribbon

300 m long, max. OD 67 mm, 1" core (ink coated outside)
11 O m long, max. OD 40 mm, 0.5" core (ink coated outside)

Ribbon Width

40 mm - 110 mm (1.6" - 4.3")

Processor

32-bit RISC CPU

Memory

• 128 MB Flash memory

• 64 MB SDRAM

Interface

• USB 2.0

• Ethernet & Serial Interface

Power

External universal switching power supply
• Input: AC 100-240V, 2.5A, 50-60Hz
• Output: DC 24V, 2.5A, 60W

Operation switch,
button, LED

1 power switch, 1 feed button & 1 LED

Sensors

• Transmissive gap sensor
• Black mark reflective sensor (position adjustable)
• Ribbon End sensor, Head open sensor

Internal fonts

• 8 alpha-numeric bitmap fonts

Bar code

• 1D bar code, Code 128UCC, Code 128 subsets A, B, C, -
EAN128, Interleaved 2 of 5, Interleaved 2 of 5 with check
digit, Code 39, Code 39 with check digit, Code 93, EAN13,
EANS, UPCA, UPCE, EAN and UPC 2 (5) digits add-on, etc.
• 2D bar code, GS1 Data Bar, GS1 Data Matrix, Maxicode etc.



Font and barcode rotation

0, 90, 180, 270 degree

Printer language

TSPL-EZD (Compatible to EPL, ZPL, ZPL II, DPL)

Media type

Continuous, die-cut, black mark, fan-fold, notched

Media width

20 - 112 mm (0.8" - 4.4")

Media thickness

0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)

Media core diameter

25.4 - 38 mm (1" - 1.5")

Label length

10 ~ 2,286 mm (0.39” ~ 40”)

Environment condition

Operation : 5 - 40°C, 25 - 85% non-condensing
Storage : -40 - 60°C, 10 - 90% non-condensing

Dealer options

Peel-off Module, • Guillotine cutter (full cut and partial cut)

Warranty

2 Year Onsite
